| Hose inner diameter | Hose Size | Hose inner diameter | Hose outer diameter | Minimum Burst Pressure | Maximum working pressure | Minimum bending radius | Ferrule | |
| mm | DASH | in | mm | mm | Mpa | Mpa | mm | |
| 5 | -03 | 3/16 | 4.8 | 9.5 | 82.7 | 20.7 | 40 | 00018-03 |
| 6 | -04 | 1/4 | 6.4 | 11.9 | 75.8 | 19.0 | 50 | 00018-04 |
| 8 | -05 | 5/16 | 7.9 | 14.3 | 68.9 | 17.2 | 60 | 00018-05 |
| 10 | -06 | 3/8 | 9.5 | 16.5 | 62.0 | 15.5 | 75 | 00018-06 |
| 12 | -08 | 1/2 | 12.7 | 20.4 | 55.2 | 13.8 | 95 | 00018-08 |
| Storage requirements for hose assemblies | |
| The storage temperature should be between 0 and 35°C, and the maximum temperature of the product during storage should not exceed 50°C. | |
| Ozone generating devices shall not be parked in the storage area. Examples include mercury vapour lamps, high-voltage electrical devices, electric motors, or other devices that produce electrical sparks or discharges. | |
| It must not be placed with corrosive products or exposed to volatile gases from these products. | |
| It should be kept away from heat sources box equipment that can generate electric field box magnetic field. | Direct sunlight or strong artificial light sources should be avoided. |
| Contact with sharp objects or the ground should be avoided. | They should be laid flat and not stacked very high. |
| Should be secured from rodents | Storage in accordance with the first-in-first-out principle |
Ensure Quality – Full CNC Machining
We adopt full CNC processing to maximize the elimination of human error, with consistency as high as 98%. Several strict inspection and cleaning procedures and a perfect system guarantee the high quality of the products.
Technology development and design
Testing of raw materials
CNC machining
Burr repair
Surface grinding machine
Surface finish detection
Ultrasonic cleaning
External processing nikel plating
Thread check gauge
Hole inner diameter dial indicator detection
Thread ring gauge detection
Semi-finished products endoscopic detection
Product assembly
Assembly drawing comparison check
