| Hydraulic solenoid valve type comparison table | ||||
| 6-Way Hydraulic Solenoid Directional Valve Model Comparison Table | ||||
| LITAND | YUKEN | Huade | VICKERS | Rexroth |
| SWH-G02-C2 | DSG-01-3C2 | 4WE6E51 | DG4V-3-2C | 4WE6E51 |
| SWH-G02-C3 | DSG-01-3C3 | 4WE6H51 | DG4V-3-0C | 4WE6H51 |
| SWH-G02-C4 | DSG-01-3C4 | 4WE6J51 | DG4V-3-6C | 4WE6J51 |
| SWH-G02-C5 | DSG-01-3C5 | 4WE6F51 | DG4V-3-1C | 4WE6F51 |
| SWH-G02-C6 | DSG-01-3C6 | 4WE6G51 | DG4V-3-8C | 4WE6G51 |
| SWH-G02-C7 | DSG-01-3C9 | 4WE6M51 | DG4V-3-7C | 4WE6M51 |
| SWH-G02-C8 | DSG-01-3C12 | 4WE6L51 | DG4V-3-3C | 4WE6L51 |
| SWH-G02-C8S | DSG-01-3C10 | 4WE6U51 | DG4V-3-31C | 4WE6U51 |
| SWH-G02-B2 | DSG-01-2B2 | 4WE6D51 | DG4V-3-2A | 4WE6D51 |
| SWH-G02-B3 | DSG-01-2B3 | 4WE6C51 | DG4V-3-0AC | 4WE6C51 |
| SWH-G02-B2S | DSG-01-2B2-L | 4WE6Y51 | DG4V-3-2A-L | 4WE6Y51 |
| SWH-G02-B20 | DSG-01-2B8 | 4WE6A51 | DG4V-3-22A | 4WE6A51 |
| SWH-G02-B40 | / | 4WE6B51 | DG4V-3-2BL | 4WE6EB51 |
| SWH-G02-D2 | DSG-01-2D2 | 4WE6b/OF51 | DG4V-3-2N | 4WE6b/OF51 |
| 10-way hydraulic solenoid valve type comparison table | ||||
| LITAND | YUKEN | Huade | VICKERS | Rexroth |
| SWH-G03-C2 | DSG-03-3C2 | 4WE10E51 | DG4V-5-2C | 4WE10E51 |
| SWH-G03-C3 | DSG-03-3C3 | 4WE10H51 | DG4V-5-0C | 4WE10H51 |
| SWH-G03-C4 | DSG-03-3C4 | 4WE10J51 | DG4V-5-6C | 4WE10J51 |
| SWH-G03-C5 | DSG-03-3C5 | 4WE10F51 | DG4V-5-1C | 4WE10F51 |
| SWH-G03-C6 | DSG-03-3C6 | 4WE10G51 | DG4V-5-8C | 4WE10G51 |
| SWH-G03-C7 | DSG-03-3C9 | 4WE10M51 | DG4V-5-7C | 4WE10M51 |
| SWH-G03-C8 | DSG-03-3C12 | 4WE10L51 | DG4V-5-5C | 4WE10L51 |
| SWH-G03-C8S | DSG-03-3C10 | 4WE10U51 | DG4V-5-51C | 4WE10U51 |
| SWH-G03-B2 | DSG-03-2B2 | 4WE10D51 | DG4V-5-2A | 4WE10D51 |
| SWH-G03-B3 | DSG-03-2B3 | 4WE10C51 | DG4V-5-0AC | 4WE10C51 |
| SWH-G03-B2S | DSG-03-2B2-L | 4WE10Y51 | DG4V-5-2A-L | 4WE10Y51 |
| SWH-G03-B20 | DSG-03-2B8 | 4WE10A51 | DG4V-5-22A | 4WE10A51 |
| SWH-G03-B40 | / | 4WE10B51 | DG4V-5-2BL | 4WE10EB51 |
| SWH-G03-D2 | DSG-03-2D2 | 4WE10b/OF51 | DG4V-5-2N | 4WE10b/OF51 |
Ensure Quality – Full CNC Machining
We adopt full CNC processing to maximize the elimination of human error, with consistency as high as 98%. Several strict inspection and cleaning procedures and a perfect system guarantee the high quality of the products.
Technology development and design
Testing of raw materials
CNC machining
Burr repair
Surface grinding machine
Surface finish detection
Ultrasonic cleaning
External processing nikel plating
Thread check gauge
Hole inner diameter dial indicator detection
Thread ring gauge detection
Semi-finished products endoscopic detection
Product assembly
Assembly drawing comparison check
