HYDRAULIC MOTOR BLOCKS TYPE BV BVT 07

HYDRAULIC MOTOR BLOCKS TYPE BV BVT 07

Type	Nominal flow rate	Adj. pressure range	Pressure ratio	Pmax.	Port threads G	Port threads G1
Type	L/min	bar		bar
BVT 3407	100	60…250	4,25:1	250	G3/4 – DIN 3852	G1/4 – DIN 3852
BVT 111607	100	60…250	4,25:1	250	1 1/16-12UN – ISO 11926	7/16-20UNF – ISO 11926
BVT 2707	100	60…250	4,25:1	250	M27x2 – DIN 3852	M14x1,5 – DIN 3852

The Hydraulic Motor Blocks Type BV BVT 07 are compact and efficient hydraulic motors designed for various industrial applications. These motor blocks integrate seamlessly into hydraulic systems to provide reliable power and torque outputs. The BV BVT 07 series is known for its robust construction and high-performance capabilities, making it suitable for demanding environments.

Features:

Compact Design: Designed for space-efficient integration into hydraulic systems without compromising performance.
High Torque Output: Provides substantial torque for powering hydraulic machinery and equipment.
Durable Construction: Built with high-quality materials to withstand harsh operating conditions.
Efficient Operation: Ensures efficient energy transfer and minimal power loss during operation.
Versatile Applications: Suitable for various industrial applications including construction, agriculture, and manufacturing.

Technical Specifications:

Model: BV BVT 07
Type: Hydraulic Motor Block

Applications:

Construction Machinery: Powers hydraulic systems in excavators, loaders, and cranes.
Agricultural Equipment: Used in tractors, harvesters, and irrigation systems.
Manufacturing: Essential for powering conveyors, presses, and industrial machinery.
Marine Applications: Suitable for use in marine hydraulic systems.

safety factor
materials	static load	dynamic load		shock load
materials	static load	repeated load	alternating load	shock load
foundry iron	4	6	10	15
mild steel	3	5	8	12
cast steel	3	5	8	15
light metal	5	6	9	15

Comparison of Materials Commonly Used for Valve Blocks
Type	Working pressure/Mpa	Thickness/mm	Manufacturability	Weldability	Cost factor
Hot-rolled steel sheet	≈35	<160	usual	usual	1
Carbon steel forgings	≈35	>160	usual	usual	1.5
Free Cutting Steel	≈35	Rods, Plates	usual	usual	1.5
Grey cast iron	≈14	——	good	unacceptable	2
Ductile iron	≈35	——	usual	unacceptable	2.1
Aluminium alloy forgings	≈21	——	good	unacceptable	3~5

Ensure Quality – Full CNC Machining

We adopt full CNC processing to maximize the elimination of human error, with consistency as high as 98%. Several strict inspection and cleaning procedures and a perfect system guarantee the high quality of the products.
